All-electric servo bending machine
High Efficiency:Fast upward/downward speed: 200 mm/s，Bending speed: 40 mm/s
High Precision：Italian GIVI Optical Encoder，Resolution: is 5 μm
High Stability:Finite element analysis、Annealing treatment、Special heavy-duty lead screws and guide rails
Low Energy Consumption：Taiwan Syntec Complete System，Standby Power Consumption: 0.3 kW/h
Maintenance-free：Automatic Centralized Lubrication，Imported Bearings，Overload and Over-travel Alarm, etc.
Plate materials: aluminum, copper, carbon steel, stainless steel
型号 | 折弯宽度 | 吨位 | 后挡行程 | 滑块行程 | 立柱间距 | 喉口深度 | 控制轴度 | 待机功耗 |
ESP16-600 | 600MM | 16T | 300MM | 180MM | 550MM | 220MM | Y+X+R | 0.15KW |
ESP35-1250 | 1250MM | 35T | 400MM | 200MM | 970MM | 330MM | Y1+Y2+X+R+Z1+Z2 | 0.3KW |
ESP40-1650 | 1650MM | 40T | 400MM | 200MM | 1370MM | 330MM | Y1+Y2+X+R+Z1+Z2 | 0.3KW |
WDB65-2500 | 2500MM | 65T | 500MM | 200MM | 2060MM | 410MM | Y1+Y2+X+R+W | 0.3KW |
