Protective Safety Fence Barrier
Physical isolation to block hazard intrusion
Warning function to enhance safety awareness
Customizable to meet diverse scenarios
Space division to standardize area management
Compliance with safety standards to avoid regulatory risks
High durability with low long-term use costs
Safety fences are standardized protective facilities that realize space demarcation, hazard isolation and safety warning through physical structures. They are widely used in scenarios such as key infrastructure, high-end industrial parks, construction sites, transportation roads, public places and industrial workshops. These fences integrate three core values: physical protection, area management and compliance adaptation, and can be customized to provide exclusive solutions according to protection levels, service cycles and environmental requirements.Safety fences are standardized protective facilities that realize space demarcation, hazard isolation and safety warning through physical structures. They are widely used in scenarios such as key infrastructure, high-end industrial parks, construction sites, transportation roads, public places and industrial workshops. These fences integrate three core values: physical protection, area management and compliance adaptation, and can be customized to provide exclusive solutions according to protection levels, service cycles and environmental requirements.
网片高度 Mesh height | 1000mm 1800mm 2000mm |
网片宽度 Mesh width | 1400mm 1200mm 1000mm 800mm 700mm 500mm 300mm 200mm |
网格尺寸 Grid size | 20x100mm |
丝径 Silk diameter | 3mm |
网片边框 Mesh frame | 20x20mm |
PC板厚度 | 3mm 4mm 5mm厚度 |
钢板 Steel plate | 1.5mm厚度 |
立柱高度 Height of column | 1200mm 2000mm 2200mm |
立柱规 Column specifications | 60x60x1.5mm 40x60x1.5mm 80x80x3mm |
光幕立柱 | 80x80mm |
地脚规格 Anchor specifications | 70x180mm 180x180x8mm |
网片连接方式 Mesh connection mode | 卡环链接、螺钉链接 Snap ring connection、screw connection |
地面连接方式Gound connection mode | 加膨胀螺栓连接 Add expansion bolt connection |
